ExtraEye - First Article Inspection Systems - X-3040T & X-4040T

ExtraEye is a hardware/software system designed to assist operators of all levels in the FAI production head validation process.The hardware part includes a chassis with motorized X/Y axes carrying a camera producing high quality images and capable of inspecting any type of component in top view up to chip 01005 format. By presenting an image of the assembled components in relation to BOM details as well as assembly drawings, ExtraEye significantly improves inspection speed, reduces operator fatigue and therefore provides accuracy of 100% inspection.

Key Features

  • Significantly improves inspection speed
  • Provides accuracy of 100% inspection
  • Reduces operator fatigue

Contact us

Technical Specification

X-3040T X-4040T
Max board size 380 x 450 mm 500 x 540 mm
Max board height 50 mm 50 mm
Image resolution 1800 DPI 1800 DPI
External size mm 680x575x380 mm 770x730x380 mm
Weight 28 kg 33 kg
Power 100-220 VAC 20W 100-220 VAC 20W
  • Semiconductor, Solar & Electronics
ExtraEyeThe Extra Eye First Article Inspection System helps you ensure your PCB assembly line is producing accurate boards, right from the start, and all the way through your production run. It streamlines every aspect of inspection, from program setup to the inspection process itself. With this easy-to-use, automated FAI system, you can dramatically shorten time-to-production, reduce end-of-line defects and improve yield. Using Extra-Eye, you’ll see lower costs and higher-quality products.
[]
