Undercounter - Dishwasher

Available models

Technical specifications
Dimensions (W/D/H)
575 / 600 / 830 mm
Loading height
356 mm
Rack size
500 x 500 mm
Capacity per hour
up to 60 racks* (1,080 plates)
Cycle times
60 sec / 180 sec
Wash temperature / Rinse Temperature
approx. 60 °C / approx. 82 °C
Tank capacity
25 l
Fresh water consumption / cycle
2.9 l
Wash pump
0.37 kW
Booster loading
3.6** (5.5) kW
Total loading
4.2** (6.0) kW
Voltage (Multiphasing)
230 V / 50 Hz / 1 (400 V / 50 Hz / 3)
Min. flow pressure
3.0 bar

Key features

  • Double-walled insulated front door
  • Automatic control of the rinse cycle
  • Integrated rinse agent dispenser
  • Heater with thermostatic control
  • Incl. electrical cable and flexible water supply hose and drain hose
  • Back panel
Technical specifications
Cycle times in sec. [1]
90 / 180 / 360 and special cycles
Water consumption
2.0 l/rack
Tank capacity
10.6 l
Tank heating
0.8 kW
Wash pump
0.6 kW / 350 l/min
Rack size
500 x 500 mm
Loading height
425 mm
Noise level
60.5 dB (A)
Weight (gross / net)
70 / 60 kg
Max. supply water temperature
60°C
Required flow rate
5 l/min
Power cord
2,000 mm

Key features

  • VISIOTRONIC Intelligent Control: ensures a simple and intuitive operating with a single button. When the display is activated by a proximity sensor, all the necessary information appears in the large display, in clear text or in the form of symbols
  • Intelligent wash water control: constantly measures the quality of the wash water and keeps the amount of rinsing needed in each rinse cycle to the minimum in order to guarantee a fully hygienic wash result. This reduces the amount of fresh water used per rinse cycle up to 2.0 l
  • Double rack system: two racks can be washed in a single wash cycle. One rack of cups can be washed underneath, while a second rack containing dishes and cutlery can also be washed above it. Thanks to the optimum use of the entire wash chamber the performance of the machine can be doubled
  • CLIP-IN Wash and Rinse Arms both the wash and rinse arms can be lifted out of the wash chamber and replaced with one hand and without any tools
Technical specifications
Cycle times in sec. [1]
80 / 150 / 170 and special cycles
Water consumption
1.0 l/rack
Tank capacity
10.6 l
Tank heating
0.8 kW
Wash pump
0.6 kW / 350 l/min
Rack size
500 x 500 mm
Loading height
425 mm
Noise level
60.5 dB (A)
Weight (gross / net)
70 / 60 kg
Max. supply water temperature
60°C
Required flow rate
5 l/min
Power cord
2,000 mm

Key features

  • VAPO RINSE ECO: switchable steam rinse cycle reduces fresh-water consumption to 1.0 l. Saving of up to 60 % water and detergent as well as up to 60 % rinse aid (compared with standard machines)
  • PERFECT Drying Manager: assistance for better drying results
  • VAPOSTOP Door System: prevents vapour to escape from machine when door is opened
  • Cutlery cycle: removes even persistent residues by the use of steam
  • STARCH REMOVAL Cleaning Cycle: removes the starch from the crockery
  • Washing HOT-TEMP: higher temperature increases the capacity up to 45 racks/h
