Koehler - Tribology - Four Ball Tester

Koehler’s Four Ball Tester determines the Wear Preventative (WP) and Extreme Pressure (EP) characteristics of lubricating oils and greases in sliding steel-on-steel applications. The test consists of rotating a steel ball under load against three stationary steel balls coated with lubricant. Measurements are taken at the rotating speeds, temperatures, and duration as specified by published standards. The load-wear index can be calculated from the weld point in EP tests, and lubricant comparisons can be made based upon scar diameters incurred from wear tests.

Available models

Koehler - Tribology - Four Ball Tester
Conformation of specifications
ASTM D2266, D2596, D2783, D4172, D5183*, IP 239
Drive Motor
1.5 kW
Test Speeds
1200, 1440, 1760 rpm
Optional Test Speeds (min/max)
1000/3000, 300/3000 rpm
Maximum Axial Load
10000 N at 3000 rpm or 12000 N at 1800 rpm
Test Duration (min/max)
1/9999 min
Test Ball diameter
12.7 mm
  • Model No: K93100
  • 220V,60 Hz
Koehler - Tribology - Four Ball Tester
Conformation of specifications
ASTM D2266, D2596, D2783, D4172, D5183*, IP 239
Drive Motor
1.5 kW
Test Speeds
1200, 1440, 1760 rpm
Optional Test Speeds (min/max)
1000/3000, 300/3000 rpm
Maximum Axial Load
10000 N at 3000 rpm or 12000 N at 1800 rpm
Test Duration (min/max)
1/9999 min
Test Ball diameter
12.7 mm
  • Model No: K93100-PN
  • 220V,60 Hz
Koehler - Tribology - Four Ball Tester
Conformation of specifications
ASTM D2266, D2596, D2783, D4172, D5183*, IP 239
Drive Motor
1.5 kW
Test Speeds
1200, 1440, 1760 rpm
Optional Test Speeds (min/max)
1000/3000, 300/3000 rpm
Maximum Axial Load
10000 N at 3000 rpm or 12000 N at 1800 rpm
Test Duration (min/max)
1/9999 min
Test Ball diameter
12.7 mm
  • Model No: K93190
  • 380V,50 Hz
Koehler - Tribology - Four Ball Tester
Conformation of specifications
ASTM D2266, D2596, D2783, D4172, D5183*, IP 239
Drive Motor
1.5 kW
Test Speeds
1200, 1440, 1760 rpm
Optional Test Speeds (min/max)
1000/3000, 300/3000 rpm
Maximum Axial Load
10000 N at 3000 rpm or 12000 N at 1800 rpm
Test Duration (min/max)
1/9999 min
Test Ball diameter
12.7 mm
  • Model No: K93190-PN
  • 380V,50 Hz

Key features

  • Conforms to ASTM D2266, D2596, IP 239, and related specifications
  • Performs Wear Preventative (WP) and Extreme Pressure (EP) tests
  • Displays and records normal load, frictional torque, time, and temperature
  • Test speeds and temperatures are electronically controlled
  • Data Acquisition Software and Card are included
  • Custom configurations are available
  • Precise variable loading capability
  • Automotive
  • Chemical
  • Machinery & Manufacturing
  • Mining & Minerals
  • Oil & Gas
  • Railway
